10kV ring network switchgear is widely used in 12 / 24KV power distribution networks such as indoor and outdoor switching stations, box-type substations, residential quarters, various office buildings, commercial centers, buildings, and factories. The product is fully sealed, fully insulated and maintenance-free design.

1、The load switch uses SF6 gas as the insulation and arc extinguishing medium

2、The circuit breaker adopts vacuum arc extinction and SF6 gas insulation

3、The operating mechanism is a spring operating mechanism

4、With automation interface

5、Equipped with shielded separable connector

6、With "five defense" function

7、Cable room with observation window

8、Equipped with safety pressure relief device

9、Optional panel type short circuit/earth fault indicator

10、The outer box is made of high-quality stainless steel, and the corresponding patterns can be painted.

1、Number of ring network cabinet units, several in and several out, optional model combination

2、Design drawings

3、Outdoor box material and appearance requirements
