Specification:
|
Type |
Main Dimensions (mm) |
||||||||
|
A |
a |
B |
H1 |
H |
L1 |
L2 |
L3 |
L |
|
|
MSC-150-1 |
150 |
70 |
8 |
- |
60 |
170 |
170 |
190 |
240 |
|
3MSC-150-2 |
150 |
70 |
8 |
- |
60 |
170 |
170 |
130 |
180 |
|
MSC-150-3 |
150 |
70 |
8 |
45 |
75 |
110 |
170 |
190 |
225 |
|
MSC-150-4 |
150 |
70 |
8 |
45 |
75 |
110 |
170 |
130 |
165 |
|
MSC-150-5 |
150 |
70 |
8 |
- |
60 |
110 |
170 |
330 |
380 |
|
MSC-200-1 |
200 |
90 |
12 |
- |
60 |
170 |
170 |
190 |
240 |
|
MSC-200-2 |
200 |
90 |
12 |
- |
60 |
170 |
170 |
130 |
180 |
|
MSC-200-3 |
200 |
90 |
12 |
15 |
75 |
120 |
170 |
190 |
255 |
|
MSC-200-4 |
200 |
90 |
12 |
15 |
75 |
120 |
170 |
130 |
195 |
|
MSC-200-5 |
200 |
90 |
12 |
- |
60 |
120 |
170 |
330 |
380 |
Note:
Suitable for telescopic connection of rectangular busbars in power plants and substation power distribution units.
The product adopts argon arc welding process, such as connection with copper equipment terminal board, please specify when ordering, plus copper aluminum composite sheet (A*L1)
|
Type |
Main Dimensions (mm) |
Failure Load ≥(kN) |
||||
|
A |
B |
H |
L1 |
L |
||
|
MGS-80 x 8 |
80 |
8.0 |
110 |
90 |
290 |
0.8 |
|
MGS-80 x 10 |
80 |
10.0 |
110 |
90 |
290 |
0.9 |
|
MGS-100 x 10 |
100 |
10.0 |
110 |
115 |
290 |
1.4 |
|
MGS-100 x 15 |
100 |
15.0 |
110 |
115 |
290 |
1.8 |
|
MGS-120 x 10 |
120 |
10.0 |
110 |
135 |
290 |
1.9 |
|
MGS-120 x 12 |
120 |
12.0 |
110 |
135 |
290 |
1.20 |
|
MGS-125 x 10 |
125 |
10.0 |
110 |
140 |
290 |
2.0 |
|
MGS-125 x 12 |
125 |
12.0 |
110 |
140 |
290 |
2.1 |
|
MGS-125 x 12.5 |
125 |
12.5 |
110 |
140 |
290 |
2.22 |
|
MGS-150 x 10 |
150 |
10.0 |
110 |
165 |
290 |
2.3 |
|
MGS-150 x 12 |
150 |
12.0 |
110 |
165 |
290 |
2.4 |
Note: The product adopts argon arc welding process
