NC Type High Voltage Electrical Energy-Efficient Composite Tension Insulator String

Classification:Insulator Fitting

Inside Road & Administration Industry & Trading Garden,Houshan Industry Area,Fuzhou City,Fujian Province

0591-22806687 0591-22806697

0591-22806667

bs@china-grid.com.cn

Overview
Description:

Composite tensile insulation string consists of composite insulator and energy-saving insulation sheet metal, which has the advantages of compact structure, convenient installation, reliable insulation, strong stain resistance and remarkable energy saving.

Model Insulation Type Clamp Type Model X Applicable cable specifications
-1 -2 -3 -4 -5
NC10-W/J-X FNB-10/70-WD NEJ 16-35 50 70-95 120-150 185-240
NC1-S/J-X FNB-1/70-DU NEJ 25-50 70-95 120 150 185-240
NC10-W/L-X FNB-10/70-WD NLL (16-70) (50-95) (70-15) (120-185) (120-300)
NC1-S/L-X FNB-1/70-DU NLL (16-70) (50-95) (70-15) (120-185) (120-300)
NC10-W/K-X FNB-10/70-WU NEK (35-70) 35(95-150) 50-95(185-240) 120(300) 150-300
NC1-S/K-X FNB-1/70-UU NEK 16-35(35-70) 50-95(95-150) 120-150(185-240) 185(300) 240-300
1. The above configuration is recommended combination, our company can be configured according to customer needs
2. The cable specifications for the stripping installation are in parentheses.
