Description:
With the wide application of high-voltage cables, it is necessary to fix the cable laying in the cable trench and the installation of the high-voltage line tower.
In order to ensure the safe operation of the cable and take into account the energy-saving factors, our company has developed a series of special high-low voltage cable fixing fittings according to different installation methods and different use places of users to meet the needs of users.
Type
|
Rated voltage
(KV)
|
Rated bending load
(KN)
|
Co-owner
"X"
|
Insulation distance
(mm)
|
Creepage distance
(mm)
|
Lightning full wave impulse withstand voltage
≥(kV)
|
Frequency withstand voltage
≥(kV)
|
Weight
(kg)
|
FSJ3-66/16B
|
66
|
16
|
986
|
737
|
1956
|
410
|
185
|
40.8
|
FSJ4-66/16B
|
66
|
16
|
1113
|
864
|
2362
|
410
|
185
|
43.1
|
FSJ2-110/12.5B
|
110
|
12.5
|
1245
|
991
|
2743
|
550
|
230
|
40.9
|
FSJ3-110/12.5B
|
110
|
12.5
|
1392
|
1143
|
3150
|
550
|
230
|
48.1
|
FSJ4-110/12.5B
|
110
|
12.5
|
1506
|
1270
|
3556
|
550
|
230
|
49.9
|
FSJ1-220/6B
|
220
|
6
|
2159
|
1930
|
5537
|
1000
|
395
|
61.2
|
FSJ2-220/6B
|
220
|
6
|
2291
|
2083
|
5944
|
1000
|
395
|
63.9
|
FSJ3-220/6B
|
220
|
6
|
2418
|
2210
|
6350
|
1000
|
395
|
66.2
|
FSJ4-220/6B
|
220
|
6
|
2680
|
2489
|
7137
|
1000
|
395
|
70.8
|
